InPower Air-cooled Dry Screw Vacuum Pumps, Extremely low noise, high reliability quality, and air cooling are the preferred products in laboratory research, semiconductor industry, plasma cleaning, instrument and equipment fields.
Model：SPIRID N65A,N100A
Ultimate vacuum: ≤1Pa
SPEED 50 Hz:65～100 L/s
SPEED 60 Hz:80～120 L/s
Technical parameters:
|
Model |
SPIRID N65A |
SPIRID N100A |
|
|
Ultimate Vacuum (50Hz) |
mbar |
0.01 |
0.01 |
|
SPEED(50Hz) |
m³/h |
62 |
108 |
|
POWER(50Hz) |
Kw |
2.2 |
2.2 |
|
Noise |
dB |
55～70 |
55～70 |
|
IN |
KF |
50 |
50 |
|
OUT |
KF |
40 |
40 |
|
Weight |
kg |
230 |
258 |
|
Size |
mm |
956*400*387 |
956*400*387 |
|
Cooling Method |
Air/Water |
Air |
Air |
Characteristic：
High performance
Advanced screw design, patented self-balancing screws, perfectly suited for chemical processes, distillation and vacuum drying.
high reliability
Made from Mazak equipment processing and manufacturing, with 23 years of experience in Dry screw manufacturing, operating over 100000 products worldwide.
Air-cooling
Air cooling, various sealing and coating configurations as well as ATEX-certified versions available.
inPower NA Air-cooled Dry Screw Vacuum Pumps Application area:
Lithium Ion Batteries
Freeze Drying
Solar Cell Manufacturing
Fine Chemicals
Thin Film Deposition
Pharmaceuticals
Automotive Coating
Industrial Glass Coating
Heat Treatment
Brazing
Plastic Extrusion
