InPower Side channel blowers, also known as regenerative blowers or ring blowers, are widely utilized in various industrial applications due to their robustness, efficiency, and ability to handle continuous operation.
Technical parameters:
|
Model |
ELG300 |
ELG400 |
ELG600 |
ELG750 |
ELG950 |
ELG1100 |
ELG1300 |
||
|
SPEED(50Hz) |
m3/h |
300 |
400 |
600 |
750 |
850 |
1100 |
1300 |
|
|
Ultimate Vacuum (50Hz) |
mbar |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
|
|
POWER(50Hz) |
KW |
4 |
5.5 |
7.5 |
11 |
15 |
18.5 |
22 |
|
|
Motor Speed(50Hz) |
rpm |
Permanent magnet frequency conversion |
|||||||
|
Noise |
dB |
55-68 |
55-68 |
55-68 |
55-74 |
55-74 |
55-74 |
55-74 |
|
|
Connect |
IN |
Inch |
DN65 |
DN65 |
DN65 |
DN80 |
DN100 |
DN100 |
DN100 |
|
OUT |
Inch |
DN65 |
DN65 |
DN65 |
DN80 |
DN100 |
DN100 |
DN100 |
|
|
Cooling Method |
Air/Water |
Air |
Air |
Air |
Air |
Air |
Air |
Air |
|
|
Weight |
Kg |
400 |
650 |
850 |
950 |
980 |
1000 |
1050 |
|
|
SIZE |
mm |
1300*820*1320 |
1300*820*1320 |
1300*820*1320 |
1500*1050*1300 |
1500*1050*1300 |
1600*1130*1500 |
1600*1130*1500 |
|
|
Model |
ELG1800 |
ELG2000 |
ELG3000 |
ELG3900 |
ELG4600 |
ELG5200 |
||||||
|
SPEED(50Hz) |
m3/h |
1800 |
2000 |
3000 |
3900 |
4600 |
5200 |
|||||
|
Ultimate Vacuum (50Hz) |
mbar |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
0.3 |
|||||
|
POWER(50Hz) |
KW |
30 |
30 |
37 |
55 |
75 |
90 |
|||||
|
Motor Speed(50Hz) |
rpm |
Permanent magnet frequency conversion |
||||||||||
|
Noise |
dB |
60-74 |
60-74 |
60-74 |
75-85 |
75-85 |
75-85 |
|||||
|
Connect |
IN |
Inch |
DN150 |
DN150 |
DN150 |
DN150 |
DN200 |
DN200 |
||||
|
OUT |
Inch |
DN150 |
DN150 |
DN150 |
DN150 |
DN200 |
DN200 |
|||||
|
Cooling Method |
Air/Water |
Air |
Air |
Air |
Air |
Air |
Air |
|||||
|
Weight |
Kg |
1500 |
1500 |
3200 |
3200 |
3600 |
3600 |
|||||
|
SIZE |
mm |
2100*1320*1680 |
2100*1320*1680 |
2100*1320*1680 |
2400*1450*1800 |
3600*1800*2100 |
3100*1800*2200 |
|||||
Characteristic：
High Efficiency: Rietschle side channel blowers are designed for high efficiency and reliable performance.
Durability: Constructed with robust materials to ensure longevity and minimal maintenance.
Oil-Free Operation: They typically provide clean, oil-free air, which is crucial for applications sensitive to contamination.
Low Noise Levels: These blowers are often designed to operate quietly, making them suitable for environments where noise reduction is important.
Versatility: Available in various models to suit different pressure and flow requirements.
Continuous Operation: Suitable for applications requiring 24/7 operation without significant wear and tear.
Application Flexibility:
Industrial Applications
Pneumatic Conveying: Used for the transport of powdered and granular materials through pipelines.
Packaging Industry: Involved in vacuum packaging, bottle filling, and labeling processes.
Plastics Industry: Used in extrusion, thermoforming, and plastic welding.
Woodworking: Employed in dust extraction systems and CNC machinery.
Environmental Technology
Water Treatment: Utilized in aeration processes for sewage treatment plants and aquaculture.
Air Pollution Control: Used in air sampling and monitoring systems.
inPower application area：
Automotive
Vacuum Holding: Employed in assembly lines for holding parts in place during manufacturing.
Testing Equipment: Used in emission testing and other vehicle performance tests.
Healthcare and Laboratories
Medical Devices: Used in respiratory therapy equipment, dental suction systems, and sterilizers.
Laboratory Equipment: Employed in vacuum filtration, aspiration, and drying processes.
Food and Beverage
Food Processing: Utilized in processes like conveying, packaging, and drying.
Beverage Production: Employed in bottling and carbonation processes.
